Polyimide Products

Resin Product description Tg °C Type/ IPC-4101 UL-94 Fabric Comments Datasheet Process Guide

33N

Kerimid 701 (V0) Non-MDA Polyimide

250

GIL /40; 41

V-0

E

Maximum Flame Retardance

35N

Kerimid 701 (V1) Non-MDA Polyimide

250

GIL /40; 41

V-1

E

Drilling enhanced

37N

Low-flow polyimide Prepreg

200

GIJ /42

N/A

E

Rigid Flex

38N

Low-flow polyimide Prepreg

200

GIJ /42

N/A

E

Rigid Flex

84N

Multifilm Hole-Fill Prepreg

250

GIL /40; 41

N/A

E

Filled 85N

84HP

high-performance ceramic-filled polyimide

>250

GIL /40; 41

HB

85HP

High Performance Polyimide

>250

GIL /40; 41; E-appx. A

Meets HB

E

Tc (W/mK) is 2x Polyimide

85N

Non-MDA Polyimide – Unmodified

250

GIL /40; 41

HB

E

Maximum Thermal Stability

HF-50

Hole-Fill Compound

250

N/A

N/A

None

Fill Clearance Holes

Epoxy & Low-flow Products

Resin Product description Tg °C Type/ IPC-4101 UL-94 Fabric Comments Datasheet Process guide

45N

Multifunctional Epoxy

170

GFG /24

V-0

E

High Layer Count MLB´s

47N

Low-flow Tetrafunctional Epoxy Prepreg

130

GFG /23

V-0

E

Rigid Flex, Heat Sinks

49N

Low-flow Multifunctional Prepreg

170

GFG /24

V-0

E

Rigid Flex, Heat Sinks

51N

Low-flow lead-free

170

GFG /124

V-0

E

Lead free soldering

Controlled Thermal Expansion

Resin Product description Tg °C Type/ IPC-4101 UL-94 Fabric Comments Datasheet Process guide

45N

CIC laminated, multifunctional Epoxy

170

GFG /24

V-0

E

CTE = 9-12 ppm/°C

45NK

Multifunctional Epoxy/Kevlar®

170

AFN /50

N/A

K

CTE = 4-7 ppm/°C

55NT

Multifunctional Epoxy/ non woven aramid

170

BFG /55

V-0

B

CTE = 7-8 ppm/°C

85N/CIC

Copper-Invar-Copper Clad Polyimide

250

GIL /40; 41

HB

E

CTE = 9-12 ppm/°C

85NT

Polyimide/ non woven aramid

240

BIL /53

N/A

B

CTE = 7-9 ppm/°C
